Overview
The P40.17 Plus is Merlo's flagship general-purpose telehandler — 4 tonnes of lift, 17 metres of reach, and a turning radius that fits Philippine site access roads. It outperforms forklifts on rough ground, replaces crane work up to two floors, and runs longer between services than any rival in its class.
Standard on every unit we deliver: BOB chassis levelling, CDC dynamic load chart, Tac-Lock quick coupler, ROPS/FOPS Level 4 cab, Tier 3 emission package, and CAMEC's 24-month parts-and-labour warranty.
Full specifications
| Max lift capacity | 4,000 kg |
| Max lift height | 16.7 m |
| Max forward reach | 13.0 m |
| Capacity at full height | 2,300 kg |
| Capacity at full reach | 500 kg |
| Engine | Deutz TCD 3.6 L4, Stage V |
| Engine power | 100 hp / 74.4 kW |
| Hydraulic system | Load-sensing flow-sharing |
| Transmission | CVTronic continuous variable |
| Max travel speed | 40 km/h |
| Operating weight | 8,700 kg |
| Turning radius (inside) | 1.55 m |
| Fuel tank | 140 L |
| Cabin | ROPS/FOPS Level IV, A/C standard |
Attachments available
Pallet forks
Standard 1200mm
General bucket
1.2 m³
Man basket
2-person, CE-cert
Hook + winch
3.5 t SWL
Jib extension
+ 4 m reach
Sweeper bucket
Site cleanup
